Your Expert Partner in High-Power Laser Cutting
Get recommended nozzles, optics & ceramic components based on your fiber laser power and cutting application.
Solutions from 6kW standard systems to 60kW ultra-high-power platforms.
Fiber Laser Solutions by Power Level
Laser Consumables
Top Sellers for Raytools/Bodor (10kW–20kW)
Fused Silica Protective Window D37*7 for Raytools (10-20kW)
Optimized for 20kW heavy-duty cutting with ultra-low thermal drift.
Material: JGS1 Grade
Absorption: <10ppm
Coating: AR/AR @1064nm
Threshold: >20J/cm²
Low Absorption
Super-High Power Laser Internal Protective Window D30*5 for Bodor (20kW+)
Engineered for continuous 20kW+ operation with Ultra-low thermal absorption for stable focus
Material: Suprasil 311
Absorption: <5ppm
Coating: Dual Band AR
Threshold: 40kW Tested
Premium Synthetic Fused Silica (Corning 7980) Protective Window D50*2 for Precitec ProCutter (15kW)
Reliable beam stability for precise 15kW stainless steel cutting.
Material: Premium High-Purity Silica
Absorption: <8ppm
Coating: High Power AR
Threshold: >25J/cm²
Extreme-Performance Protective Window D34*5 for Trumpf (20kW-40kW+)
Superior beam stability for ultra-high-power 40kW cutting. Zero burst risk under extreme thermal load.
Material: PQ161G
Absorption: <10ppm (Ultra-Low Thermal Lens)
Coating: 40kW-Grade AR @1030nm
Threshold: 40kW Stable / 50kW Peak Tested
Fused Silica Protective Window D32*3.5 for Amada LCG/ENSIS (12kW)
Specifically designed for high-clarity beam delivery in Amada heads.
Material: Top-Grade JGS1
Absorption: <10ppm
Coating: AR/AR Coating
Threshold: 15kW Tested
40kW Tested
Ultra-Pure Quartz Window D38*2 for Raytools (20kW+)
Enhanced thermal endurance for high-frequency 40kW cutting pulses.
Material: Suprasil 3002
Absorption: <5ppm (Typical <3ppm)
Coating: V-AR Coating
Threshold: 40kW Pulse Tested
Low Absorption
Suprasil Grade Window D55*1.5 for Bodor P40/P40L Series (20kW-40kW)
Maximum clarity for 40kW+ systems, reducing nozzle heat-up.
Material: Suprasil 312
Absorption:<5ppm (Ultra-low Thermal Drift)
Coating: Ultra-Power AR
Threshold: 40kW+ Tested / Ultra-High Power Rating
Focus Lenses for High-Precision Cutting
USA CVD ZnSe Focus Lens D20-F50.8 for Precitec (10kW)
Optimized for high-precision fine cutting with peak thermal stability and minimal spot distortion.
Material Grade
Absorption
Coating
Threshold
USA CVD ZnSe
AR / AR @10.6um
< 0.15%
15kW / cm²
Fused Silica Dual Focus Lens D37-F150 for Raytools (15kW)
Engineered for high-power fiber lasers to provide consistent focal point positioning under varied loads.
Material Grade
Absorption
Coating
Threshold
Fused Silica
High Purity AR
< 10ppm
40J / cm²
High-Power Specials for Precitec/Bodor P40
Featured SKU
Fused Silica Protective Window D50*2 for Precitec (20kW–40kW+)
Engineered for zero thermal drift during extreme 40kW+ continuous cutting operations. Extreme heat resilience.
Material
Absorption
Coating
40kW+ Tested
Imported JGS1 Fused Silica
< 15ppm
Double-Sided AR @ 1064nm
Hero SKU
Grade A Fused Silica Protection D55*1.5 for Bodor P40 (20kW–40kW+)
Optimized for Bodor P40 heads. Superior edge consistency and thermal stability under ultra-high power density.
Material
Absorption
Coating
Low Absorption
Premium Fused Silica Grade A
< 10ppm
High-Power AR @ 1064-1080nm
Hero SKU
Ultra-High Pressure Protective Window D34*5 for BOCI (12kW–40kW+)
Specifically reinforced for BOCI BLT series heads. Engineered to withstand high gas pressure and prevent thermal deformation in 40kW+ environments
Material
Absorption
Coating
High-Pressure Pro
Premium Fused Silica Grade A
< 10ppm
High-Power AR @ 1064-1080nm
Edge
Built for Stable High-Power Cutting
Muxi Precision integrates protective optics, nozzles, ceramics, and sensor systems as one matched chain, keeping your beam path stable from source to cutting head.
Power Level
Beam Path Stability
Sensor Feedback
Uptime
Cut Quality
Support
Endorsed by Top Industrialists
"
"
"
Integrating Muxi components ensured stable power transmission across our 30kW array with zero thermal drift issues.
Their optics remain stable under high heat loads, making them the most reliable partner for our global distribution.
Muxi provided stable beam transmission gear that eliminated our thermal warping during thick plate heavy cutting.
Julian Vance
Robert Sterling
Marcus Thorne
Plant Director
Supply Manager
Lead Scientist
Verify Technical Proposals
Provide your operational specs for a tailored assessment. We ensure your laser transmission remains stable even under the most extreme thermal conditions.
Consumables Technical FAQ
1. Compatibility with Cutting Heads & Brands
Our consumables are engineered to precise OEM specifications for major brands including Precitec, Raytools, WSX, and Bodor. We ensure 100% mechanical compatibility and optical alignment for power levels up to 60kW.
2. Lens & Nozzle Lifetime Under High Power
Under typical 20kW-40kW operational loads, our protective windows maintain stability for 150-200 hours depending on clean-room standards. Nozzles utilize high-conductivity alloys to resist thermal deformation, extending service life by 30% compared to standard copper alternatives.
3. Cleaning and Maintenance Best Practices
Always use spectroscopic grade ethanol or IPA (>99.5%) with lint-free swabs. For high-power optics, cleaning should be performed in a dust-free environment to prevent point-source absorption which leads to thermal cracking. Never reuse swabs across different optics.
4. Choosing Specs for Power & Material
Selection depends on the assist gas (Oxygen vs. Nitrogen) and power density. For >20kW Nitrogen cutting, we recommend double-layer nozzles with optimized aerodynamics to ensure stable gas flow. Our engineering team provides custom spreadsheets matching focal length to plate thickness.
5. Lead Time, Custom Sizes & Global Stock
Standard components are stocked for immediate dispatch (24-48h). Custom sizes or specialized AR/VR coatings require 10-15 business days for precision manufacturing and testing. We provide global door-to-door shipping with full technical documentation for B2B buyers.
